Introduction

Most paving¹ and drainage relies on fall to carry away the water to somewhere less troublesome. Fall may also be referred to as slope or, more correctly, gradient. By making one part of the pavement or drainage pipe higher than another, gravity can be relied upon to persuade the water in a preferred direction.

But how much fall is enough? And can you have too much?

[1] The most obvious exceptions are permeable paving, where the water goes through the surface and into the ground, and some land drains which are laid flat and then rely on hydrostatic pressure to drive the water one way or the other.

 ribbon

Types of Fall:

The term 'fall' is often used in relation to paving and drainage, but it is sometimes further qualified by talking about endfall and crossfall.

Endfall:

This is also known more corectly as longitudinal fall and it describes the fall or gradient along the length of a pavement or surface.



Crossfall:

Known more correctly as transverse fall, it describes the fall or gradient across the breadth of a pavement or surface.
endfall and crossfall
Endfall and crossfall
On some pavements, notably those covering larger areas such as plazas and bigger car parks, it's not always possible to determine just which direction is endfall or which is crossfall. It may be that the project engineer has arbitrarily decided that one particular orientation is longitudinal and so is represented as endfall, and perpendicular to that will be the crossfall.

However, in such situations, it's often easier just to talk about "fall" full stop!

 ribbon

Understanding Gradient

There needs to be some universally understood method for describing how much slope or fall there is on any given structure, such as a pavement or a pipe. The way this is achieved is by measuring how much that structure rises or falls over a specified distance.

As shown in the diagram below, it should be apparent that a pipe measuring 1m in length which is 100mm higher at one end than the other (blue) has more fall than a pipe with 50mm difference over the same distance (red), or a pipe that has that 100mm of difference over a 1.5m length (yellow).

various gradients
These two values, namely amount of difference in level and the distance over which that difference occurs, are used to define any given gradient. In the useful easy-to-remember equation used for the remainder of this page, the level difference is referred to as "Rise" (or fall) while the distance is referred to as "Run".
Gradient = Rise ÷ Run

gradient = rise over run

 ribbon

Expressing Fall

This equation results in a dimensionless value or ratio that allows direct comparison between various slopes. In the examples used above...
100mm ÷ 1000mm = 0.1

50mm ÷ 1000mm = 0.05

100mm ÷ 1500mm = 0.067

These values are most commonly converted into percentages ....
0.1 = 10%

0.05 = 5%

0.067 = 6.7%

.... but percentages can be hard, if not impossible, to visualise, so a more commonly encountered method of expression is as "1 in summat" ratios ...
0.1 = 10% = 1 in 10

0.05 = 5% = 1 in 20

0.067 = 6.7% = 1 in 15

A gradient of, for example, 1 in 45 means there is 1 unit of fall (or rise) for every 45 units of run.

That could be 1 metre of fall over 45 metres of run, or 1 inch of fall over 45 inches of run, or 1 mile of fall over 45 miles.

Gradient ratios are dimensionless, so as long as the units of rise/fall and run are the same, the ratio holds true.

 ribbon

Converting between ratios and percentages

A gradient expressed as a percentage can be converted to a ratio by dividing 100 by the percentage value:
15.9% .... 100 ÷ 15.9 = 6.29 so the ratio is 1 in 6.29 (1:6.29)
definition of gradient

A gradient expressed as a ratio can be converted to a percentage by diving 100 by the denominator of the ratio:
1:24 ... 100 ÷ 24 = 4.166' = 4.17%


Calculators:

pavingexpert calculators
To convert a gradient percentage to a ratio:

Gradient = %

...is equivalent to a ratio of...


1:
To convert a gradient ratio to a percentage:

Ratio = 1:

...is equivalent to a gradient of...


%

 ribbon

Finding fall per metre:

To determine the amount of fall (or rise) from a ratio:

Example 1:

A residential patio is to be built and it will drain towards the garden area. The patio will be 4.2m wide and fall for this project is required to be 1:60.

What is the level difference between the garden edge and where the paving meets the house?

patio plan
A gradient of 1:60 means that there will be 1 unit of fall for every 60 units of patio width.

The patio is to be 4.2m wide, so if that distance (the run) is divided by 60, the result is the 1 unit of fall. We'll work in millimetres rather than metres...

From the above....
Fall = 4,200mm ÷ 60 = 70mm
So, there needs to be 70mm of fall across the patio.

To check: 1:60 = 1÷60 = 0.0167

70 ÷ 4200 = 0.0167

Example 2:

A surface water pipe linking a road gully to a manhole is required to be laid at a gradient of 1:90

Calculate the amount of fall per metre.

1 ÷ 90 = 0.011m = 11mm


calculator
Fall Calculator

Enter distance (run) and gradient required:

Distance = metres

Gradient = 1:

You will need approximately.....
mm of fall over that distance

Which is equivalent to...
mm of fall per linear metre

calculator

 ribbon

Some regularly used falls:

regularly used falls
